REDARC 160W Monocrystalline Solar Blanket

This 160W monocrystalline solar blanket is the perfect off-the-shelf solution to provide you with portable solar power when you're out 4WDing, camping or just hitting the beach over the weekend.

Our flexible and convenient solar blankets are packed with more value than ever, REDARC’s monocrystalline solar blankets can be folded up into a neat package and offer flexibility that’s not available with fixed or folding panels. Drape it over the bonnet or windscreen, lay it on the ground or hang it from the side of your awning. When it’s time to hit the road, just fold it up and pack it away.

Solar blanket for 4WD and caravan travel

With genuine industry standard Anderson™ SB™50 connectors, setting up camp is easier than ever. These high-quality Anderson™ plugs are simple and fast to connect with no screw terminals and no risk of poor connections from frayed wires or loose terminals – just plug and play!

REDARC 160W Monocrystalline Solar Blanket Features

• Designed for portability and strength with efficient monocrystalline cells
• Lightweight and highly portable
• The lightest REDARC solar option
• Anti-reflective scratch resistant with ETFE coating
• Genuine Industry Standard Anderson™ SB™50 plug connection
• Designed for 12V Automotive, Marine and Recreational Vehicle battery systems
• High power output

Pair your REDARC solar blanket with a trusty DC charger or lithium portable power station so you and your family can travel further for longer with all the comforts you want from home.

SpecificationsSpecifications More Information

gtin_barcode	9338628006885
brand	REDARC
Solar Cell Type	Monocrystalline
Open Circuit Voltage	21.5V
Watts	160W
Frame or Material	Canvas
Max. Power Voltage	18V
Recommended Regulator	SRPA Anderson™ Regulator
Standby Current	<10mA (12V) / <4.5mA (24V)
Short Circuit Current	9.5A
Operating Temperature	+32°F to +185°F
Cable Length	4.7" (120 mm)
Weight	10.5 lb (4.8 kg)
height	0.1" (1.2 mm)
width	29.1" (740 mm)
depth | length	64.4" (1635 mm)
Warranty	2 Years
Dimensions Open	64.4" x 29.1" x 0.1" (1635 x 740 x 2.5 mm)
Dimensions Closed	14.4" x 14.4" x 2.8" (365 x 365 x 50 mm)
Power Tolerance	± 5%
Max Power Current	8.9A
Connector Type	Anderson™ SB™ 50
Peak Power	160W
